Product Introduction
This product is a micropitting protection industrial gear oil specifically designed for heavy-duty industrial gear systems. It is suitable for gear transmission systems operating under long-term high stress, impact loads, and boundary lubrication conditions.
Solutions
Micropitting Control Mechanism
This product achieves gear surface protection through a stable lubricating film and surface protection mechanism:
- Forms a stable EHL (Elastohydrodynamic Film) lubricating film in the rolling-sliding contact area
- Reduces the probability of direct contact with micro-roughness peaks
- Reduces local contact stress concentration
- Delays the formation and propagation of microcracks
Extreme Pressure Anti-Wear System
- Employs a sulfur-phosphorus extreme pressure additive system (Sulfur-Phosphorus EP System)
- Forms a chemical protective film under high temperature and pressure
- Effectively prevents direct metal-to-metal contact and scuffing
- Improves resistance to impact loads
Fatigue Resistance and Lubrication Stability
- Reduces the risk of fatigue pitting on gear surfaces
- Improves the wear resistance of gear surfaces
- Improves lubrication continuity and stability
- Extends oil drain interval (depending on operating conditions)
Thermal & Oxidation Stability
- Highly refined base oil system
- Resistance to high-temperature oxidation and sludge formation
- Maintains system cleanliness during long-term operation
- Reduces the risk of acidic substance formation
Application Scenarios
Heavy Industry Gear Systems
- Mining Crusher Gearboxes
- Cement Rotary Kiln Drive Systems
- Metallurgical Heavy-Duty Gear Transmission Systems
Low-Speed, High-Torque Equipment
- Conveyor Drives
- Crusher Gearboxes
- Rolling Mill Gearboxes
Impact Load Equipment
- Steel Industry Main Drive Systems
- Port Machinery Gearboxes
- Heavy-Duty Industrial Mixing and Drive Systems
Technical Data
|
Test Item |
Test Method |
Result (Typical Range) |
|
ISO Viscosity Grade |
ISO VG |
150 / 220 / 320 / 460 |
|
Kinematic Viscosity @40°C |
ASTM D445 |
140–480 mm²/s |
|
Kinematic Viscosity @100°C |
ASTM D445 |
14.5–31.0 mm²/s |
|
Viscosity Index |
ASTM D2270 |
90–105 |
|
Flash Point |
ASTM D92 |
220–260°C |
|
Pour Point |
ASTM D97 |
-12 to -30°C |
|
Density @15°C |
ASTM D4052 |
0.86–0.90 g/cm³ |
|
FZG Load Stage |
DIN ISO 14635 |
12–14 (typical 13+) |
|
Four-Ball Wear Scar |
ASTM D4172 |
0.30–0.45 mm |
|
Copper Corrosion |
ASTM D130 |
1a |
Trust & Authority
Production Quality System
ISO 9001:2015 Quality Management System
Standardized Lubricant Blending Process Control
Testing and Validation System
FZG Gear Load Test (DIN Standard Method)
Four-Ball Extreme Pressure Wear Test
Oxidation Stability and Thermal Stability Test
Batch Consistency Control
Batch Traceability System
Viscosity Control Accuracy ±5% (Typical Range)
Raw Material Grading Management System
Compliance
DIN 51517 Part III (CLP)
ISO 12925-1 CKD
AGMA 9005 EP (Compliant)
OEM/Wholesale Supply Capabilities
OEM/ODM Services
- Supports customization for different ISO/VG standards
- Private brand packaging (OEM Label)
- Formula optimized for specific operating conditions
Supply Capabilities
- Stable, large-volume supply of industrial-grade products
- Supports 200L drums / IBC containers / bulk packaging
- Long-term, stable supply system
Export Support
- Complete MSDS / TDS / COA documentation
- Standardized export packaging
- Familiar with international shipping and trade terms
FAQ
